Someone please help. Problem with my target AR


Reply

LinkBack Thread Tools Display Modes
Old 01-01-2013, 01:04 AM   #11
Feedback Score: 0 reviews

DarinCraft's Avatar

Join Date: Jan 2010
Location: CA
Posts: 1,179
Liked 25 Times on 13 Posts
Likes Given: 8

Default

Someone please help. Problem with my target AR - AR-15 Discussion
This is the gas port on the barrel. You can see the shroud of carbon around the port and some blow by on the shelf.
Someone please help. Problem with my target AR - AR-15 Discussion
Another view
Someone please help. Problem with my target AR - AR-15 Discussion
gas port on the block. You can see some blow by on the gas tube.
Someone please help. Problem with my target AR - AR-15 Discussion
Another view of the gas block
Someone please help. Problem with my target AR - AR-15 Discussion
Receiver end of the gas tube

From what I can see it looks like I have some sealing problems in the gas block. Now is it because the ports aren't lining up, or another problem? How do I insure the two ports line up?

Thanks for the help guys


__________________
Quote:
"A strong body makes the mind strong. As to the species of exercises, I advise the gun. While this gives moderate exercise to the body, it gives boldness, enterprise and independence to the mind. Games played with the ball, and others of that nature, are too violent for the body and stamp no character on the mind. Let your gun therefore be your constant companion of your walks."
Thomas Jefferson
From the great speaker...er uh Barak Obongo

"Liberals make great proctologists. They're the only ones who truly know what the inside of an anus looks like."~me
DarinCraft is offline

Reply With Quote
Old 01-01-2013, 06:34 AM   #12
Feedback Score: 0 reviews

Quentin's Avatar

Join Date: Apr 2010
Location: Northwest
Posts: 7,526
Liked 1823 Times on 1178 Posts
Likes Given: 1769

Default

Well if you temporarily remove the gas tube from the block then a bent paper clip through the gas block will help you line up with the barrel's gas port. I read that somewhere and think it was Sniper03 who gave that tip.


__________________
______
The biggest issue with assembling an AR isn't so much getting the parts together right - it's getting the right parts together.
________________________________________
US Army 1966-69, VFW Life Member, Retired Geek
Quentin is online now
fsted2a Likes This
Reply With Quote
Old 01-02-2013, 05:27 AM   #13
Feedback Score: 0 reviews

Jpyle's Avatar

Join Date: Aug 2009
Location: Sewell,NJ
Posts: 4,844
Liked 783 Times on 453 Posts
Likes Given: 499

Default

Darin:

What Quentin suggested will work fine. An alternative albeit more lengthy process is to first make sure the opening in the tube lines up with the port in the gas block when pinned...this will determine if the gas block and the tube are in spec or need replacing. Now remove the tube from the gas block and align the port in the tube with the port in the barrel so that the center of the tube port is centered with the barrel port. Using a black sharpie make an index mark on the tube and barrel to be used to align the gas block. Insert the tube back in the gas block, making sure the port is facing down towards the barrel, and pin it securely. Slide the gas block onto the barrel and align the index mark on the tube with the index mark on the barrel making sure the tube is aligned straight to the opening in the barrel nut and receiver. Tighten down the gas block. At this point the barrel, tube and block ports should be in perfect front-to-back and side-to-side alignment. Relying on the shoulder cut in the barrel to align the gas block can be problematic if the ports on the barrel or gas block are the tiniest bit out of spec...not uncommon on some barrels, also that shoulder is cut to allow for a hand guard cap so the gas block is actually about 1/16" forward...

A little opinion here, those 2 screw blocks are notorious for leaking, I would recommend a different attachment type if possible.
__________________
"The whole of the Bill (of Rights) is a declaration of the right of the people at large or considered as individuals.... It establishes some rights of the individual as unalienable and which consequently, no majority has a right to deprive them of." (Albert Gallatin of the New York Historical Society, October 7, 1789)

"A free people ought not only to be armed and disciplined, but they should have sufficient arms and ammunition to maintain a status of independence from any who might attempt to abuse them, which would include their own government." - George Washington

Last edited by Jpyle; 01-02-2013 at 05:37 AM.
Jpyle is offline

Reply With Quote
Old 01-02-2013, 06:32 AM   #14
Feedback Score: 0 reviews

DarinCraft's Avatar

Join Date: Jan 2010
Location: CA
Posts: 1,179
Liked 25 Times on 13 Posts
Likes Given: 8

Default

Thank you for the great help. I will get a different block and follow your procedure. I am also getting an a2 stock assembly. If that didn't work then the spring is getting cut. Thank you again guys.
__________________
Quote:
"A strong body makes the mind strong. As to the species of exercises, I advise the gun. While this gives moderate exercise to the body, it gives boldness, enterprise and independence to the mind. Games played with the ball, and others of that nature, are too violent for the body and stamp no character on the mind. Let your gun therefore be your constant companion of your walks."
Thomas Jefferson
From the great speaker...er uh Barak Obongo

"Liberals make great proctologists. They're the only ones who truly know what the inside of an anus looks like."~me
DarinCraft is offline

Reply With Quote
Old 01-02-2013, 06:18 PM   #15
Feedback Score: 0 reviews

Jpyle's Avatar

Join Date: Aug 2009
Location: Sewell,NJ
Posts: 4,844
Liked 783 Times on 453 Posts
Likes Given: 499

Default

Quote:
Originally Posted by DarinCraft
Thank you for the great help. I will get a different block and follow your procedure. I am also getting an a2 stock assembly. If that didn't work then the spring is getting cut. Thank you again guys.
If you get an A2 stock you will need a new tube spring and buffer anyway. You do have a carbine length spring and buffer now right?
__________________
"The whole of the Bill (of Rights) is a declaration of the right of the people at large or considered as individuals.... It establishes some rights of the individual as unalienable and which consequently, no majority has a right to deprive them of." (Albert Gallatin of the New York Historical Society, October 7, 1789)

"A free people ought not only to be armed and disciplined, but they should have sufficient arms and ammunition to maintain a status of independence from any who might attempt to abuse them, which would include their own government." - George Washington
Jpyle is offline

Reply With Quote
Old 01-02-2013, 06:48 PM   #16
Feedback Score: 0 reviews

DarinCraft's Avatar

Join Date: Jan 2010
Location: CA
Posts: 1,179
Liked 25 Times on 13 Posts
Likes Given: 8

Default

Yes. I put the carbine on there because that was all I had. Thanks again.
__________________
Quote:
"A strong body makes the mind strong. As to the species of exercises, I advise the gun. While this gives moderate exercise to the body, it gives boldness, enterprise and independence to the mind. Games played with the ball, and others of that nature, are too violent for the body and stamp no character on the mind. Let your gun therefore be your constant companion of your walks."
Thomas Jefferson
From the great speaker...er uh Barak Obongo

"Liberals make great proctologists. They're the only ones who truly know what the inside of an anus looks like."~me
DarinCraft is offline

Reply With Quote
Old 01-23-2013, 07:12 AM   #17
Feedback Score: 0 reviews

DarinCraft's Avatar

Join Date: Jan 2010
Location: CA
Posts: 1,179
Liked 25 Times on 13 Posts
Likes Given: 8

Default

I have to say thanks to JPyle. He was correct. There was too much blow by around the gas tube. It was also leaking between the barrel and the gas block. I put a YHM GB on it and the problem went away.

Thank you to JPyle and all those who replied.
__________________
Quote:
"A strong body makes the mind strong. As to the species of exercises, I advise the gun. While this gives moderate exercise to the body, it gives boldness, enterprise and independence to the mind. Games played with the ball, and others of that nature, are too violent for the body and stamp no character on the mind. Let your gun therefore be your constant companion of your walks."
Thomas Jefferson
From the great speaker...er uh Barak Obongo

"Liberals make great proctologists. They're the only ones who truly know what the inside of an anus looks like."~me
DarinCraft is offline

Reply With Quote
Old 01-23-2013, 06:13 PM   #18
Feedback Score: 0 reviews

fsted2a's Avatar

Join Date: Apr 2008
Posts: 1,618
Liked 372 Times on 293 Posts
Likes Given: 640

Default

Quote:
Originally Posted by Quentin View Post
Well if you temporarily remove the gas tube from the block then a bent paper clip through the gas block will help you line up with the barrel's gas port. I read that somewhere and think it was Sniper03 who gave that tip.
I am glad the problem has already been resolved, but I have another method of lining the gas block on the barrel. I take a straight edge and draw a line with some white out from the port to past where the gas block will end. Then I make another line from the port on the gas block to where it mounts on the barrel. When I put the gas block on the barrel, I just make sure the lines touch and I am good to go. The white out can be wiped off without scratching the barrel and no one knows it wasn't mounted at the factory.


__________________
"Democracy is two wolves and one sheep voting on what to have for dinner.
Liberty is the well-armed lamb contesting the vote." - Benjamin Franklin
fsted2a is offline
Quentin Likes This
Reply With Quote
